Watlow manufactures a variety of RTD sensors that are specially designed to ensure precise and repeatable temperature measurement. Watlow sensors are built to meet the most demanding industrial applications while providing a lower total cost of ownership for our customers.STYLES OF WATLOW RTD SENSORS AVAILABLE:
The Watlow Style RB RTDs have standard, insulated leads with an internal heat transfer plate for a quick time response and high accuracy. These RTDs are also epoxy sealed to resist moisture and pull out. There is a standard 260°C (500°F) potting. Style RB RTDs are constructed of 316 stainless steel for a durable, rigid sheath with temperature from -50 to 260°C (-58 to 500°F). They are manufactured in diameters from 0.125 to 0.250 inches.
RTD Style RB-G 0.125 Diameter Build-A-Product
RTD Style RB-H 0.188 Diameter Build-A-Product
RTD Style RB-J 0.250 Diameter Build-A-Product
The Watlow Style RC RTDs are manufactured with durable connectors with copper pins for plug or jack termination applications. These provide simple connection to extension leads and have a 200°C (400°F) temperature rating. In addition, the RTD has a crimp compression adapter that assures superior connector attachment with high accuracy and dependable readings. Style RC RTDs are constructed of 316 stainless steel for a durable, rigid sheath with temperature from -50 to 260°C (-58 to 500°F). They are manufactured in diameters from 0.125 to 0.250 inches.
The Watlow Style RF RTDs are constructed of flexible, mineral insulation that provides a bendable and highly durable sensor. It is manufactured with stainless steel transitions that are crimped to the sheath and filled with 260°C (500°F) epoxy (brazing is optional). These sensors have a coiled spring for strain relief, which protects the lead wire against sharp bends in the transition area. The RF RTD has a -200 to 650°C (-328 to 1200°F) temperature rating with dependable readings and high accuracy. They are manufactured in diameters from 0.125 to 0.250 inches.
The Watlow Style RR RTDs are “connection head” style come with a choice of 5 different connection heads. The RR RTD has a -200 to 650°C (-328 to 1200°F) temperature rating with dependable readings and high accuracy. They are manufactured in diameters from 0.125 to 0.250 inches.
Current lead time is 12-14 weeks, FOB: Carson, CA.
